Hanashield High Gloss Finish

Name: Hanashield High Gloss Finish
SKU: 138938
Availability: InStock

Price range: RM28.50 through RM141.80

Hanashield High Gloss Finish is a high gloss waterborne paint that is easy to use and has excellent gloss and weathering properties.

Size

Clear

Request Quote

[ht-ctc-chat call_to_action="Whatsapp Enquiry" pre_filled="Hello ,I would like to inquire on {{url}}" style=8]

Wishlist

SKU: N/A Category: HanaShield Tags: glossy surface, lacquer finish

Weight	N/A
Features	Environmental Friendly, Low VOC, Weather Resistance
Size	1 Litre, 2 Litres, 5 Litres
Paints	Interior Paint, Exterior Paint
Colors	Blue, Brown, Green, Grey, Orange, Red, Violet, White & Black, Yellow
Brown	Antelope, Beaver Brown, Beige Brown, Black Brown, Brown, Chestnut Brown, Chocolate Brown, Clay Brown, Conifer, Copper Brown, Fawn Brown, Green Brown, Grey Brown, Juniper, Mahogany Brown, Nut Brown, Ochre Brown, Olive Brown, Orange Brown, Pale Brown, Pearl Copper, Red Brown, Sepia Brown, Signal Brown, Terra Brown
Blue	Azure Blue, Black Blue, Blue, Brilliant Blue, Capri Blue, Cirrus, Cobalt Blue, Cornflower, Distant Blue, Dolphin, Dresden, Gentian Blue, Green Blue, Grey Blue, Larkspur, Light Blue, Midnight, Night Blue, Ocean Blue, Pastel Blue, Pearl Gentian, Pearl Night Blue, Pigeon, Pigeon Blue, Pinefrost, Pompadour, Regatta, Sapphire Blue, Signal Blue, Sky Blue, Steel Blue, Trafalgar, Traffic Blue, Turquoise Blue, Ultramarine Blue, Viking, Violet Blue, Water Blue
Orange	Apricot, Azalea, Blood Orange, Bright Red Orange, Cameo, Clementine, Deep Orange, Luminous Bright Orange, Luminous Orange, Lupin, Pastel Orange, Pearl Orange, Poppy, Pure Orange, RAL Orange[3], Red Orange, Salmon Orange, Shell, Signal Orange, Traffic Orange, Yellow Orange
Green	Black Green, Black Olive, Blue Green, Bottle Green, Braemar, Brown Green, Brown Olive, Chromium Green, Citrine, Duckegg, Emerald Green, Fern Green, Fir Green, Garland, Grass Green, Green, Grey Olive, Greyfriar, Hollybush, Ivy Green, Leaf Green, Lido, Light Green, Linden, Luminous Green, May Green, Mint Green, Mint Turquoise, Moss Green, Olive Green, Opal Green, Orion, Pale Green, Pastel Green, Pastel Turquoise, Patina Green, Pearl Green, Pearl Opal Green, Pine Green, Pure Green, Reed Green, Reseda Green, Scarab, Sherwood, Signal Green, Springleaf, Traffic Green, Turquoise Green, Verona, Yellow Green, Yellow Olive
Grey	Agate Grey, Anthracite Grey, Basalt Grey, Beige Grey, Black Grey, Blue Grey, Brown Grey, Cement Grey, Chive, Concrete Grey, Dusty Grey, Flint Grey, Goosewing, Granite Grey, Graphite Grey, Green Grey, Grey, Iron grey, Ironstone, Khaki Grey, Light Grey, Loganberry, Merlin, Moss Grey, Mouse Grey, Olive Grey, Pearl Mouse Grey, Pebble Grey, Platinum Grey, Quartz Grey, Raven, Rhino, Signal Grey, Silk Grey, Silver Grey, Slate Grey, Squirrel Grey, Stone Grey, Tarpaulin Grey, Telegrey 1, Telegrey 2, Telegrey 4, Tideway, Traffic Grey A, Traffic Grey B, Turtle, Umbra Grey, Vandyke, Window Grey, Woodash, Yellow Grey
Red	Antique Pink, Bamboo, Beige Red, Black Red, Brown Red, Brownstone, Carmine Red, Cinnamon, Copper Beech, Coral Red, Flame Red, Fontana, Light Pink, Mace, Mallow, Monarch, Nectarine, Oxide Red, Petal, Plum, Purple Red, Red, Rose, Rosepetal, Rosevale, Ruby Red, Saddle, Sandstone, Signal Red, Strawberry Red, Tawny, Tea Rose, Tomato Red, Traffic Red, Wine Red
Violet	Blue Lilac, Claret Violet, Heather, Heather Violet, Pageant, Pastel Violet, Pearl Blackberry, Pearl Violet, Purple Violet, Red Lilac, Red Violet, Regalia, Signal Violet, Telemagenta, Traffic Purple, Violet
White, Black & Silver	Alpine, Black, Clean Room White, Cream, Dove, Flake Grey, Gardenia, Graphite Black, Grey Aluminium, Grey White, Heron, Honeysuckle, Jet Black, Magnolia, Papyrus White, Pearl Dark Grey, Pearl Light Grey, Portland, Pure White, Signal Black, Signal White, Silver, Traffic Black, Traffic White, White Aluminium
Yellow	Aztec, Beige, Bison, Bracken, Broom Yellow, Brown Beige, Buttermilk, Canary Yellow, Capricorn, Catkin, Colza Yellow, Curry, Daffodil Yellow, Dahlia Yellow, Florida, Forsythia, Goldcup, Golden Yellow, Green Beige, Grey Beige, Honey Yellow, Hopsack, Ivory, Jonquil, Lemon Yellow, Light Ivory, Lizard, Luminous Yellow, Maize Yellow, Melon Yellow, Moorland, Ochre Yellow, Olive Yellow, Oyster White, Pastel Yellow, Pearl Beige, Pearl Gold, Pollen, Saffron Yellow, Sand Yellow, Savannah, Seaweed, Sierra, Signal Yellow, Sulfur Yellow, Sun Yellow, Traffic Yellow, Willow, Yellow, Zinc Yellow

Description

Hanashield High Gloss Finish is a single component, near-zero VOC, 100% pure acrylic base high gloss waterborne paint. It has excellent gloss and weathering properties and is easy to use. It is suitable for most areas of ship and coastal steel structures, industrial applications, and wood finish. It has excellent mechanical and physical properties for heavy-duty applications. The paint is compatible with ColorVista WB Colorant for a colorful high gloss finish.

Features

Excellent gloss and weathering properties.
Easy to use – spray, brush, roller
General purpose high gloss lacquer.
Suitable for most areas of the ship and coastal steel structures, industrial applications, and wood finish.
Excellent mechanical and physical properties for heavy-duty application
Compatible with ColorVIsta WB Colorant for a colorful high gloss finish.
Compatible with ColorVista-WB Cool+ Heat Reflective Colorant to formulate IR heat reflective gloss finish for energy saving on air conditioning

Typical Uses

Suitable for use as protective coating and finishing for various parts of the ship such as accommodation, superstructures, engine room, industrial application, and wood finish. Recommend to use for steel structures at coastal areas such as refineries, mining facilities, power plants, bridges, buildings, and steel installation as well as wood high gloss lacquer. Can use with ColorVista Colorant for a high gloss colored top coat.

Physical Data

Color	:	As specified
Density	:	1.2 +/- 0.05
Volume Solid	:	45+/- 2%
VOC(as supplied)	:	<50g/L
Shelf Life @25⁰C / indoor	:	24 months

Typical Thickness: 40 ~ 60µ dried film.

Drying Time(at Dry Film Thickness 40µ)	Temperature	10⁰C	20⁰C	30⁰C
	Surface Dry	30min	20min	10 min
	Hard Dry	2.5 hrs	1.5 hrs	1.0 hrs
Painting interval:	Minimum	2.5 hrs	1.5 hrs	1.0 hrs
Painting interval:	Max. (self)	–	–	–
Theoretical coverage (at DFT 40- 60µ)		0..088~0.133 L/m²; 11.3 ~ 7.5m²/L
Service temperature		-60 to 120⁰C (dry)

Application Data

Mixing ratio: Not Applicable

Application Method: airless spray, roller, brush

Mixing Procedure :	Mix for at least two minutes or until homogeneous.
Drying schedule :	Drying by water evaporation and air dry lacquer. Higher film thickness, insufficient ventilation, or lower temperature will require longer drying time.

This product requires the substrate temperature to be above the dew point ( + 3~5 ⁰ C). Condensation due to substrate temperatures below the dew point can cause flash rust on metal and adhesion will be affected.

Similarly, the paint under sunlight exposure may fade and chalk.

Application Procedure

Mix properly the paint before use.

Flush equipment with fresh water before use.
Mix the paint until homogeneous.
Thin with water only if necessary for workability.
When applying by conventional spray, use adequate air pressure and volume for proper atomization.
Apply a wet coat in even parallel passes, overlapping 50% to avoid holidays and pinholes.
Excessive thickness can prolong drying and sagging.
Clean up all equipment with water immediately after use.
Keep containers tightly close and store them in a proper storage area.

Condition of Application

Use a brush or roller with a 1/8″ nap. Apply at a sufficient thickness and avoid repeating rolling to have good leveling.

Temperature	:	Min 5 ⁰ C ; Max 50 ⁰ C
Humidity	:	Maximum 85 % R.H.
For Airless spray:-
Tip Size	:	Graco 615, 715 or equivalent
Paint Output pressure	:	10.7 – 13.8 MPa (g)
Viscosity	:	1.5 ~ 2.0 Pa.s
Thinning	:	0 – 10 % by volume

Surface Preparation

General :

Surfaces must be clean and dry, and all contaminants like dirt, dust, and oil must be removed by appropriate methods to ensure good adhesion.

Wood Finish :

The wood surfaces should be prepared and apply one coat of HanaShield High Gloss Lacquer in 50 -75 micron wet film thickness as a sealer. Allow to dry and sand with 280-320 grit sandpaper.

Apply 1 -2 coats by roller, brush but ideally by spray for a smooth finish at around 30 microns of dried film thickness each. Keep from freezing.

The moisture content of wood should be no higher than 9% and must be free of any surface contaminants. Final sand wood no finer than 150 grit sandpaper and remove all sanding dust.

Shop primed steelwork:

The Weld seam and the damaged area should be cleaned to a minimum St3 or SSPC-SP3. The shop-primed steelwork should be repaired for any rust and free from any contaminant with suitable secondary surface preparation such as spot blast, sweeping, or power tooling. Apply the primer and middle coat.

Safety Precaution & Clean-Up

Safety :	Read and follow the material safety data sheet (MSDS) before use. Employ normal safety precautions. Put on necessary personal protection equipment when handling and using this product.
Ventilation :	when working in a confined workplace, thorough air ventilation must be used during and after application until the coating is cured. The ventilation system should be effective to prevent solvent vapor concentration from reaching a lower explosion limit for the product and to ensure exposure limit to the personnel is below the permissible exposure limit.
Caution :	All electrical equipment and installations should be made and properly grounded. In areas where explosion hazards exist, workmen should be used non-ferrous tools and conductive and non-sparkling shoes.
Clean-up :	Use Hana Paint polyurethane thinner (Hana Thinner U) or hydrocarbon solvent for cleaning. Observe safety precautions when using the solvents. In case of spillage, absorb and dispose of the material and used container according to local required regulations or through a licensed waste collector.

Disclaimer & Limited Warranty

Disclaimer

Data, specifications, directions, and recommendations given in this data sheet represent test results or experience obtained under controlled or specially defined circumstances. Their accuracy, completeness, or appropriateness under the actual conditions of any intended use is not guaranteed and must be determined by the user. The products are delivered and any technical assistance is given subject to our GENERAL CONDITIONS OF SALE, DELIVERY, AND SERVICE and, unless otherwise expressly agreed in writing, manufacturer and seller assume no liability in excess of that stated therein for results obtained, injury, direct or consequential damage incurred from the use as recommended above or otherwise.

Limited Warranty

Whilst we endeavor to ensure that all advice we give about this product is correct and manufactured according to the standard quality control system, however, we have no control over either the quality or condition of the substrate or many other factors affecting the use and application of the product. Therefore, unless we specifically agree in writing to do so, we do not accept any liability whatsoever or howsoever arising for the performance of the product or for any loss or damage arising out of the use of this product.
