Hanashield Exterior

Name: Hanashield Exterior
SKU: 138936
Availability: InStock

Price range: RM27.00 through RM128.30

Hanashield Exterior Coating is a high-performance, multi-purpose elastomeric paint coating that protects concrete, wood, and metal finishes.

Size

Clear

Request Quote

[ht-ctc-chat call_to_action="Whatsapp Enquiry" pre_filled="Hello ,I would like to inquire on {{url}}" style=8]

Wishlist

SKU: N/A Category: HanaShield Tags: exterior paint, outdoor paint

Weight	N/A
Features	Environmental Friendly, Odour-less, Weather Resistance
Paints	Exterior Paint
Size	1 Litre, 2 Litres, 5 Litres, 400 ml
Colors	Blue, Brown, Green, Grey, Orange, Red, Violet, White & Black, Yellow
Brown	Antelope, Beaver Brown, Beige Brown, Black Brown, Brown, Chestnut Brown, Chocolate Brown, Clay Brown, Conifer, Copper Brown, Fawn Brown, Green Brown, Grey Brown, Juniper, Mahogany Brown, Nut Brown, Ochre Brown, Olive Brown, Orange Brown, Pale Brown, Pearl Copper, Red Brown, Sepia Brown, Signal Brown, Terra Brown
Blue	Azure Blue, Black Blue, Blue, Brilliant Blue, Capri Blue, Cirrus, Cobalt Blue, Cornflower, Distant Blue, Dolphin, Dresden, Gentian Blue, Green Blue, Grey Blue, Larkspur, Light Blue, Midnight, Night Blue, Ocean Blue, Pastel Blue, Pearl Gentian, Pearl Night Blue, Pigeon, Pigeon Blue, Pinefrost, Pompadour, Regatta, Sapphire Blue, Signal Blue, Sky Blue, Steel Blue, Trafalgar, Traffic Blue, Turquoise Blue, Ultramarine Blue, Viking, Violet Blue, Water Blue
Green	Black Green, Black Olive, Blue Green, Bottle Green, Braemar, Brown Green, Brown Olive, Chromium Green, Citrine, Duckegg, Emerald Green, Fern Green, Fir Green, Garland, Grass Green, Green, Grey Olive, Greyfriar, Hollybush, Ivy Green, Leaf Green, Lido, Light Green, Linden, Luminous Green, May Green, Mint Green, Mint Turquoise, Moss Green, Olive Green, Opal Green, Orion, Pale Green, Pastel Green, Pastel Turquoise, Patina Green, Pearl Green, Pearl Opal Green, Pine Green, Pure Green, Reed Green, Reseda Green, Scarab, Sherwood, Signal Green, Springleaf, Traffic Green, Turquoise Green, Verona, Yellow Green, Yellow Olive
Grey	Agate Grey, Anthracite Grey, Basalt Grey, Beige Grey, Black Grey, Blue Grey, Brown Grey, Cement Grey, Chive, Concrete Grey, Dusty Grey, Flint Grey, Goosewing, Granite Grey, Graphite Grey, Green Grey, Grey, Iron grey, Ironstone, Khaki Grey, Light Grey, Loganberry, Merlin, Moss Grey, Mouse Grey, Olive Grey, Pearl Mouse Grey, Pebble Grey, Platinum Grey, Quartz Grey, Raven, Rhino, Signal Grey, Silk Grey, Silver Grey, Slate Grey, Squirrel Grey, Stone Grey, Tarpaulin Grey, Telegrey 1, Telegrey 2, Telegrey 4, Tideway, Traffic Grey A, Traffic Grey B, Turtle, Umbra Grey, Vandyke, Window Grey, Woodash, Yellow Grey
Orange	Apricot, Azalea, Blood Orange, Bright Red Orange, Cameo, Clementine, Deep Orange, Luminous Bright Orange, Luminous Orange, Lupin, Pastel Orange, Pearl Orange, Poppy, Pure Orange, RAL Orange[3], Red Orange, Salmon Orange, Shell, Signal Orange, Traffic Orange, Yellow Orange
Red	Antique Pink, Bamboo, Beige Red, Black Red, Brown Red, Brownstone, Carmine Red, Cinnamon, Copper Beech, Coral Red, Flame Red, Fontana, Light Pink, Mace, Mallow, Monarch, Nectarine, Oxide Red, Petal, Plum, Purple Red, Red, Rose, Rosepetal, Rosevale, Ruby Red, Saddle, Sandstone, Signal Red, Strawberry Red, Tawny, Tea Rose, Tomato Red, Traffic Red, Wine Red
White, Black & Silver	Alpine, Black, Clean Room White, Cream, Dove, Flake Grey, Gardenia, Graphite Black, Grey Aluminium, Grey White, Heron, Honeysuckle, Jet Black, Magnolia, Papyrus White, Pearl Dark Grey, Pearl Light Grey, Portland, Pure White, Signal Black, Signal White, Silver, Traffic Black, Traffic White, White Aluminium
Violet	Blue Lilac, Claret Violet, Heather, Heather Violet, Pageant, Pastel Violet, Pearl Blackberry, Pearl Violet, Purple Violet, Red Lilac, Red Violet, Regalia, Signal Violet, Telemagenta, Traffic Purple, Violet
Yellow	Aztec, Beige, Bison, Bracken, Broom Yellow, Brown Beige, Buttermilk, Canary Yellow, Capricorn, Catkin, Colza Yellow, Curry, Daffodil Yellow, Dahlia Yellow, Florida, Forsythia, Goldcup, Golden Yellow, Green Beige, Grey Beige, Honey Yellow, Hopsack, Ivory, Jonquil, Lemon Yellow, Light Ivory, Lizard, Luminous Yellow, Maize Yellow, Melon Yellow, Moorland, Ochre Yellow, Olive Yellow, Oyster White, Pastel Yellow, Pearl Beige, Pearl Gold, Pollen, Saffron Yellow, Sand Yellow, Savannah, Seaweed, Sierra, Signal Yellow, Sulfur Yellow, Sun Yellow, Traffic Yellow, Willow, Yellow, Zinc Yellow

Description

Hanashield Exterior Coating is a high-performance, multi-purpose elastomeric coating based on 100% acrylic emulsion. It has excellent flexibility, adhesion, and weathering properties to protect concrete, wood, and metal finishes. The coating is easy to use and can be applied with a brush, roller, or sprayer. It is suitable for ship accommodation areas, industrial applications, and concrete or masonry substrates. The coating resists fungus and algae growth and has excellent anti-carbonation properties.

Features

Good weathering properties.
Easy to use: spray, brush, roller
General purpose Water base exterior finish.
Suitable for the accommodation of ships, industrial applications, concrete walls, and wood finish.
Resistant to fungus and algae growth
Easy application and good leveling property.
Excellent anti-carbonation property
Good flexibility to fill and prevent hairline crack
High water vapor permeability
Environmental friendly product and free from harmful chemicals such as APEO &formaldehyde

Typical Uses

High-grade elastomeric emulsion system with excellent decorative and protective functions for all internal and external masonry surfaces such as brickwork, concrete, plaster, textured surfaces, wood, and metal finish. Suitable for use as protective coating and finishing for various parts of the ship such as accommodation, superstructures, engine room, industrial application, and concrete and masonry substrate.

Physical Data

Color	:	As specified
Volume Solid	:	50 +/- 2%
Solid Content	:	60 +/- 2%
VOC(as supplied)	:	<50g/L
Shelf Life @25⁰C / indoor	:	24 months

Typical Thickness: 40 ~ 60µ dried film.

Drying I Time(at Dry Film Thickness 50µ)	Temperature	10⁰C	20⁰C		30⁰C
	Surface Dry	50min	40min		30min
	Hard Dry	5 hrs	3 hrs		2 hrs
Painting interval:	Minimum	5 hrs	3 hrs		2 hrs
	Max. (self)	–	–		–
Pot LIfe		–		–	–
Theoretical coverage (at DFT 40- 60m)		0.08~0.12 L/m²; 12.5 ~ 8.3 m²/L
Service temperature		-20 to 120⁰C (dry)

Application Data

Mixing ratio: not applicable

Application Method: airless spray, roller, brush

Mixing Procedure :	Hand stir for at least two minutes or until homogeneous.
Drying schedule :	Drying by water evaporation. Higher film thickness, insufficient ventilation, or lower temperature will require longer drying time.

This product requires the substrate temperature to be above the dew point ( + 3~5 ⁰ C).

Application Procedure

Mix properly the paint before use.

Flush equipment with water before use.
Mix the paint thoroughly until homogeneous.
Thin with water only if necessary for workability.
When applying by conventional spray, use adequate air pressure and volume for proper atomization.
Apply a wet coat in even parallel passes, overlapping 50% to avoid holidays and pinholes.
Excessive thickness can prolong drying and sagging.
Clean up all equipment with water immediately after use.
Keep containers tightly close and store them in a proper storage area.

Condition of Application

Use a brush or roller with a 1/8″ nap. Apply at a sufficient thickness and avoid repeating rolling to have good leveling.

Temperature	:	Min 5 ⁰ C ; Max 50 ⁰ C
Humidity	:	Maximum 85 % R.H.
For Airless spray:-
Tip Size	:	Graco 615, 715 or equivalent
Paint Output pressure	:	10.7 – 13.8 MPa (g)
Viscosity	:	1.5 ~ 2.0 Pa.s
Thinning	:	0 – 10 % by volume
Recommended Painting system	:	1 coat of Hana Shield Sealer 1-2 coats of Hanashield Exterior

Surface Preparation

General :

Surfaces must be clean and dry, and all contaminants like dirt, dust, and oil must be removed by appropriate methods to ensure good adhesion.

Moisture:

Ensure the surface is dry before painting. Moisture must be < 4% before application

Concrete Structure:

Concrete must be cured for at least 30 days prior to coating and must be free from moisture as much as possible. The surface must be cleaned, and free from any contaminant, laitance, and loose film. Broom cleaning, vacuum cleaning, air blast cleaning, and steam and water cleaning are suitable as outlined in ASTM D4258.

Contaminants:

Remove dust and foreign matter by cleaning with a damp cloth. Remove oil or grease using mild detergent and allow the surface to dry.

Safety Precaution & Clean-Up

Safety :	Read and follow the material safety data sheet (MSDS) before use. Employ normal safety precautions. Put on necessary personal protection equipment when handling and using this product.
Ventilation :	when working in a confined workplace, thorough air ventilation must be used during and after application until the coating is cured. The ventilation system should be effective to prevent solvent vapor concentration from reaching a lower explosion limit for the product and to ensure exposure limit to the personnel is below the permissible exposure limit.
Caution :	All electrical equipment and installations should be made and properly grounded. In areas where explosion hazards exist, workmen should be used non-ferrous tools and conductive and non-sparkling shoes.
Clean-up :	Use Hana Paint polyurethane thinner (Hana Thinner U) or hydrocarbon solvent for cleaning. Observe safety precautions when using the solvents. In case of spillage, absorb and dispose of the material and used container according to local required regulations or through a licensed waste collector.

Disclaimer & Limited Warranty

Disclaimer

Data, specifications, directions, and recommendations given in this data sheet represent test results or experience obtained under controlled or specially defined circumstances. Their accuracy, completeness, or appropriateness under the actual conditions of any intended use is not guaranteed and must be determined by the user. The products are delivered and any technical assistance is given subject to our GENERAL CONDITIONS OF SALE, DELIVERY, AND SERVICE and, unless otherwise expressly agreed in writing, manufacturer and seller assume no liability in excess of that stated therein for results obtained, injury, direct or consequential damage incurred from the use as recommended above or otherwise.

Limited Warranty

Whilst we endeavor to ensure that all advice we give about this product is correct and manufactured according to the standard quality control system, however, we have no control over either the quality or condition of the substrate or many other factors affecting the use and application of the product. Therefore, unless we specifically agree in writing to do so, we do not accept any liability whatsoever or howsoever arising for the performance of the product or for any loss or damage arising out of the use of this product.
