Hydura WB 500
Price range: RM35.20 through RM137.50
A two components water base epoxy floor coating that is suitable as sealing primer and finishing for industrial flooring and concrete surfaces.
- Additional information
- Description
- Features
- Typical Uses
- Physical Data
- Application Data
- Application Procedure
- Condition of Application
- Surface Preparation
- Safety Precaution & Clean-Up
- Disclaimer & Limited Warranty
- Need Help?
- Reviews (0)
| Weight | N/A |
|---|---|
| Colors | Black, Biru, coklat, Buff, Cream, hijau, kelabu, Light Brown, Light Grey, Jingga, merah, Silver, Violet, White, Putih hitam, Kuning |
| Features | |
| Paints | |
| Size |
Description
A two components water base epoxy floor coating that is suitable as sealing primer and finishing for industrial flooring and concrete surfaces.
Features
- Excellent adhesion to green and aged concrete.
- Easy to use – spray, brush , roller
- General purpose Water base epoxy coating.
- Suitable for heavy duty industrial application and concrete flooring.
- Excellent mechanical and physical properties for heavy duty application
Typical Uses
Suitable for use as protective coating , primer and finishing for industrial application and concrete flooring. Recommend to use for all type of green and aged concrete flooring, rooftop and concrete surfaces.
Physical Data
| Color | : | As specified |
| Volume Solid | : | 65 +/- 2% |
| VOC(as supplied) | <50g/L | |
| Shelf Life @250C / indoor | : | 24 months |
Typical Thickness : 50 ~ 100m dried film.
| Drying Time(at Dry Film Thickness 50m) | Temperature | 100C | 200C | 300C
|
||
| Surface Dry | 8.5 hrs | 7.5hrs | 5.5 hrs | |||
| Hard Dry | 15 hrs | 13 hrs | 10 hrs | |||
| Painting interval: | Minimum | 15 hrs | 13 hrs | 10 hrs | ||
| Max. (self) | – | – | – | |||
| Pot LIfe | 2.5 hrs | 1.5hrs | 45 min | |||
| Theoretical coverage
(at DFT 50- 100m) |
0..077~0.154 L/m2 ;
12.9 ~ 6.5 m2/L |
|||||
| Service temperature | -60 to 150 0C (dry) | |||||
Application Data
Mixing ratio : Part A : Part B = 80 : 20 ( by weight)
Application Method : airless spray, roller, brush
| Mixing Procedure : | Add part B into part A and power mix for at least two minutes or until homogeneous. |
| Drying schedule : | Drying by water evaporation and chemical cross linking. Higher film thickness, insufficient ventilation, or lower temperature will require longer drying time. Excessive humidity or condensation on the surface can interfere with the drying cause discoloration and may result in a surface haze.Any haze or contamination must be removed by water washing before recoating. |
This product requires the substrate temperature to be above the dew point ( + 3~5 0 C). The Epoxy finish tends to chalk or yellowing under uv exposure.
Application Procedure
Mix properly the paint before use.
- Flush equipment with epoxy thinner before use.
- Mix the paint (part A and Part B accordingly to mixing ratio) thoroughly until homogeneous.
- Thin with water only if necessary for workability.
- When applying by conventional spray, use adequate air pressure and volume for proper atomisation.
- Apply a wet coat in even parallel passes, overlap 50% to avoid holidays and pin hole.
- Excessive thickness can prolong drying and sagging.
- Clean up all equipment with thinner immediately after use.
- Keep containers tightly close and store in proper storage area
Condition of Application
Use brush or roller with 1/8” nap . Apply at sufficient thickness and avoid repeating rolling to have good levelling.
| Temperature | : | Min 5 0 C ; Max 50 0 C | ||
| Humidity | : | Maximum 85 % R.H. | ||
| For Airless spray :- | ||||
| Tip Size | : | Graco 615, 715 or equivalent
|
||
| Paint Output pressure | : | 10.7 – 13.8 MPa (g) | ||
| Viscosity | : | 1.5 ~ 2.0 Pa.s | ||
| Thinning | : | 0 – 10 % by volume | ||
Surface Preparation
| General : |
| Surfaces must be clean and dry, all contaminants like dirt, dust , oil must be remove by appropriate method to ensure good adhesion. |
| Abrasive blast clean: |
| Abrasive blast clean to Sa 2.5 (ISO-8501) or SSPC-SP6. In case of hydro blasting or hydro jetting to remove existing coating, ginger rust should be remove and blow dry before application. Surface profile must be a minimum of 50 microns. |
| Concrete Structure: |
| Concrete must be cured for at least 30 days prior to coating and must be free from moisture as much as possible. The surface must be cleaned, free from any contaminant, laitance and loose film. Broom cleaning, vacuum cleaning, air blast cleaning, steam and water cleaning are suitable as outlined in ASTM D4258. |
| Shop primed steelwork: |
| Weld seam and damaged area should be cleaned to a minimum St3 or SSPC-SP3. The shop primed steelwork should be repair for any rust and free from any contaminant with suitable secondary surface preparation such as spot blast , sweeping or power tooling. Apply the primer and middle coat. |
Safety Precaution & Clean-Up
|
Safety : |
Read and follow the material safety data sheet (MSDS) before use. Employ normal safety precautions. Put on necessary personal protection equipment when handling and using this product. |
| Ventilation : | when working in a confined workplace, thorough air ventilation must be used during and after application until the coating is cured. The ventilation system should be effective to prevent solvent vapor concentration from reaching a lower explosion limit for the product and to ensure exposure limit to the personnel is below the permissible exposure limit. |
| Caution : | All electrical equipment and installations should be made and properly grounded. In areas where explosion hazards exist, workmen should be used non-ferrous tools and conductive and non-sparkling shoes. |
| Clean-up : | Use Hana Paint polyurethane thinner (Hana Thinner U) or hydrocarbon solvent for cleaning. Observe safety precautions when using the solvents. In case of spillage, absorb and dispose of the material and used container according to local required regulations or through a licensed waste collector. |
Disclaimer & Limited Warranty
Disclaimer
Data, specifications, directions, and recommendations given in this data sheet represent test results or experience obtained under controlled or specially defined circumstances. Their accuracy, completeness, or appropriateness under the actual conditions of any intended use is not guaranteed and must be determined by the user. The products are delivered and any technical assistance is given subject to our GENERAL CONDITIONS OF SALE, DELIVERY, AND SERVICE and, unless otherwise expressly agreed in writing, manufacturer and seller assume no liability in excess of that stated therein for results obtained, injury, direct or consequential damage incurred from the use as recommended above or otherwise.
Limited Warranty
Whilst we endeavor to ensure that all advice we give about this product is correct and manufactured according to the standard quality control system, however, we have no control over either the quality or condition of the substrate or many other factors affecting the use and application of the product. Therefore, unless we specifically agree in writing to do so, we do not accept any liability whatsoever or howsoever arising for the performance of the product or for any loss or damage arising out of the use of this product.
Need Help?
Send Us An Email
Contact us at info@awatrahana.com or call us at +60143989049 for questions related to this products or send us a form via the contact form below.
